Printing |
Resolution |
203dpi (High Resolution and High Speed) |
|
Printing method |
Thermal Transfer/Direct Thermal |
|
|
Printing speed |
4-5 Inch/s |
|
|
Max printing width |
104mm (4.09 ) |
|
|
Max printing Length |
2286mm (90 ) |
|
|
Interface |
U、US、USPE(USB+ Serial+Parallel+Ethernet) |
|
|
Commands |
TSC |
|
|
Ribbon Length |
Max 300M |
|
|
Ribbon width |
Min. 30mm; Max. 110mm |
|
|
Media |
Max Media Roll OD |
127mm (5" ) |
|
Min Media Roll ID |
25mm |
|
|
Media Paper Type |
Continuous, gap, fan hold, black mark, |
|
|
Media Rolling Up Method |
Printing side outward Rolling |
|
|
Media width |
Max 120mm (4.72"), Min: 20mm (0.78") |
|
|
Media Roll Core Size |
25.4mm~38mm |
|
|
Media Gap |
Min.2mm |
|
|
Media Thickness |
0.058mm~0.305mm |
|
|
Label Length |
10mm~2286mm |
|
|
Accessories |
External Media Holder (Optional) |
|
|
Software |
Editing Software |
Nicelabel SE |
|
Driver |
Windows 2000、XP、Vista、Win7、Win8、Windows Server 2003&2008 |
|
|
Character font |
Character Set |
GB18030 (Simplified Chinese) |
|
Print font |
ASCII Font A: 12*24 |
|
|
ASCII Font B: 9*24 |
||
|
Chinese: 24*24 |
||
|
Environment |
Temperature |
Working: 5-45°C, Storage: -10~50°C |
|
Specification |
Humidity |
Working : 25%~85% ; Storage: 10%~90% |
|
Power supply |
Input: AC 110V/240V, Output: DC24V/2.5A,60W |
|
|
Storage |
4MB |
|
